Pocket Filter

Activated Carbon Pocket Filter

Product Features

Common Applications:
Suitable for office buildings, airports, hospitals and other air-conditioning ventilation systems to improve indoor air quality

Features:
The filter bag is composited by high- adsorption activated carbon fiber and filter media, with fine surface adsorption ability. It can get rid of the odor, sulfur dioxide and other volatile organic pollutants in the air effectively.

Consult now

Technical Parameters

Filter Class	Dimensions WHD(mm)	Pockets	Filter Area(㎡)	Rated Airflow(m³/h)	Initial Resistance(Pa)	Recommended Final Resistance(Pa)
G3	595595600	6	4.64	3400	20	150
	495595600	5	3.87	2800	20	150
	295595600	3	2.32	1700	20	150
G4	595595600	6	4.64	3600	35	200
	495595600	5	3.87	3000	35	200
	295595600	3	2.32	1900	35	200
F5	595595600	6	4.64	4250	45	250
	495595600	5	3.87	3650	45	250
	295595600	3	2.32	2100	45	250
